MC3000 Charger

SK-100083
MC3000
The Most advanced Cylindrical Battery
Charger & Analyzer
INSANE PERFORMANCE
German Persistence Meets Chinese Wisdom: Innovation is sparked!
The rigorous, even Stubborn German engineer played the leading role in designing the product. MCU-based high-accuracy is implemented in the making of this industry-renowned MC3000.
MC3000 is versatile and suitable for various cylindrical and multi-chemistry batteries, with Delta V to detect the full charge accurately.
The charging speed can be up to 3A, with higher precision accuracy of 0.01V.
Various utilities are integrated, PC can control and monitor the charger with data exportable for further analyze the battery's performance and health, including the battery's internal resistance.
Built-in Bluetooth definitely enhances the experience with the free app for your smartphone.
Multi-Chemistry & Various Cylindrical Battery
Fast & Accurate
Compact Interface
Enough Parameters
Easy Programming
Tilting Stand
No-nonsense Modes
Maximum Safety
APP Control
PC Control
360 VIEM
0%
    Multi-Chemistry
    Support 9 + battery chemistries
    NiMH NiCd NiZn RAM Eneloop
    • Charge current: Max. 3A (x4 slots)
    • Discharge current: Max. 2A (x4 slots)
    • Internal Accuracy**
    • (calibrated w/ accurate calibration source)
    • Voltage: < |±2mV|
    • Current: < |±2mA|
    • *The charger's accuracy will depend on the calibration source in the circumstance of self-calibration.
    Lilo4.35 LiFePO4 LTO Lilon
    • Charge current: Max. 3A (x4 slots)
    • Discharge current: Max. 2A (x1 slot)
    • Max. 1A (x4 slots)
    • Display Resolution
    • Voltage: 0.01V
    • Current: 0.01A
    Support 44+ battery sizes
    Effective Cooling
    The built-in aluminum cooler effectively dissipates heat generated in the inside of the charger to the environment, even at slow fan speed.
    Effective Cooling
    The built-in aluminum cooler effectively dissipates heat generated in the inside of the charger to the environment, even at slow fan speed.
    Compact Display
    The 128x64 pixels screen shows 5 different views during operation, see a picture as shown of Total Overview (TOV).
    Rich User Interface
    Eight Buttons for easy programming and operation. Four Slot Number Buttons (SNB) help to address the different slots. The other four buttons are for programming and operation.
    Easy Programmability
    In Simple and Advanced UI modes, the charger operates off 30 user-defined operation profiles. The programs can be called up and run with a few clicks, very conveniently.
    Battery IR Measurement
    for Recognizing Battery Health
    The charger is capable of measuring the battery internal resistance of each slot accordingly, which helps the user recognize the battery's performance and health!
    Heavy Duty Spring Slider
    A special process polishes the spring slider to ensure that the battery is in solid contact and charged efficiently.
    Flame-retardant Material Improves Safety
    UL94 V0 rated flame-retardant PC+ABS enhances the safety of the charging process.*
    *For overall safety against fire risk, DO OPERATE the charger according to the manual with all CAUTIONS highlighted!
    Secure Stand
    Rubber feet and strong tilt stand elements provide a firm stand. Tilted position enhances viewing angle and cooling air flow at the bottom side.
    No-nonsense Modes
    of Your Battery
    There are total 6 operation modes ('Break_in' for NiMH/NiCd/Eneloop batteries only, 'Storage' for Li-Chemistry batteries only).
    CHARGE
    Charge the battery at the selected rate. Suitable for frequently used batteries.
    DISCHARGE
    Discharge the batteries at the selected rate.
    Cycle
    Performs charge-dicharge cycle for up to 99 times. Cycle mode can remove memory effect of rechargeable batteries.
    Refresh Analyze
    Suitable for batteries stored for more than two weeks but less than 3 months or the batteries showing poor performance. This mode can also determine the battery capacity for battery matching.
    Storage
    Charge/Discharge a Lithium battery to a voltage which is, theoretically, better for storing a long time while maintaining the maximum of its lifespan.
    Break-in
    Applicable for new batteries and those stored for more than three months. The BREAK-IN mode is to activate the battery with a small charge and discharge rate in a charge-discharge-charge sequence.
    This process is also well-known as BATTERY FORMATTING!
    Smart Control With App
    Bluetooth(BLE) enables you to easily control the charger and view real-time data and graphs via the mobile app.
    PC Control
    You can start charging control via MC3000 Monitor.
    What’s in the Box
    MC3000
    AC Switching Adaptor
    AC Power Cord
    Instruction Manual
    Specifications
    Input Power
    DC 11-18V/4A
    Charge Current Range
    0.05-3.00A
    Discharge Current Range
    0.05-2.00A
    Max. Charge Power
    50W
    Max. Discharge Power
    15W
    Battery Chemistry Type
    NiMH, NiCd, NiZn, Eneloop,Lithium-Ion, LiIo4.35, LiFePO4,RAM,LTO
    Battery Capacity
    100-50000mAh
    Operating Temperature
    0-40℃
    USB Power Output
    DC 5V/2.1A
    Dimensions(LxWxH)
    200×124×69mm
    Weight(Without DC Adaptor)
    600g
    Manuals
    MC3000 Instruction Manual V1.15 _2403(DE) pdf
    2024-03-13
    MC3000 Instruction Manual V1.20_2403 pdf
    2024-03-13
    Cheat Sheet for MC3000 with FW V1.13 (FR) pdf
    2020-04-14
    Cheat Sheet for MC3000 with FW V1.13 (ES) pdf
    2023-10-08
    MC3000 Instruction Manual (CN) V1.6_2403 pdf
    2024-03-13
    Cheat Sheet for MC3000 with FW V1.13 (DE) pdf
    2023-10-08
    Cheat Sheet for MC3000 with FW1.13 (EN) pdf
    2023-10-08
    Software
    MC3000_Monitor_V1.05.zip zip
    Windows
    Firmware
    MC3000_Firmware_Update__V1.18.zip zip
    2023-05-25
    MC3000_Firmware_Update_V1.15.zip(MACOS≥10.15) zip
    2020-03-30
