80W AC/DC
Balance Charger / Discharger / Power Supply
As the enhanced version of e660, SkyRC e680 is suitable for all current battery types: LiPo, Li-ion, LiFe, NiCd, NiMH, PB and also new generation LiHV with end voltage 4.35V, with the maximum 80W charge power and 8A charge current. Especially it supports DJI Mavic Battery with maximum 4A charge power.
Power Supply
Battery Voltage
Meter
Battery Resistance
Meter
TVC
LiHV Battery
Mode
DJI Mavic
Battery
AGM & Cold
Charge Mode
Bigger Cooling
Fan
e680 is capable of operating as a power supply with a maximum output of 80 watts so that it helps the hobbyists to power the DC equipment.
Cooling Fun
Output Socket 4mm Banana Plug
AD/ DC Inout
Temperature Sensor Port
DC Power Supply
SkyRC e680 charger is integrated with DC power supply, which output voltage is 13.8V with power ranging from 10W to 80W. That is really convenient for drivers to power their DC devices, such as tire warmer, Pit light, etc.
Support Charging DJI Mavic Battery
SkyRC e680 can charge DJI Mavic battery with the maximum charge current of 4A. The Mavic charging cable(SK-600023-06) is not included in the package. You need to purchase it separately.
AGM & Cold
Charge Modes for PB Battery
SkyRC e680 can charge AGM battery and also can be used for charging PB battery at very low temperatures.
Thermal Cutoff
Battery internal chemical reaction will cause the battery temperature to rise. When the temperature limit is reached, the process will be terminated. This function is available by connecting optional temperature sensor cable (SK-600040-01), which is not included in the package. You need purchase it separately.
18
Smart & Efficient Cooling System
Temperature controlled 8000rpm high speed sleeve bearing cooling fan effectively blows the air through the extruded aluminum heat sink, effectively cooling the device.
8000rpm
We are Certified, We are Qualified!
Our products comply with the laws and regulations into each country we ship. Our products are designed, tested and approved to meet worldwide standards for Product Safety, Electromagnetic Compatibility and other regulatory compulsory requirements, when used for their intended purpose.
Manuals
e680 Instruction Manual V1.0 pdf
2019-06-05
